| SYSTEM INFORMATION |
| Rated AC Power |
100kW |
| Rated Capacity |
215kWh |
| BATTERY INFORMATION |
| Cell Type |
LFP |
| Cell Capacity |
280Ah |
| Configuration |
240S1P |
| Rated Voltage |
768V |
| Voltage Range |
672～864V |
| Charge/Discharge Rate |
≤0.5C |
| Depth of Discharge |
98% |
| INVERTER INFORMATION |
| Maximum AC Power |
105kVA |
| Operation Mode |
Supports Grid-Tied &Off-Grid Operation |
| Rated Grid/Island Voltage |
400Vac |
| Grid Voltage Range |
323～456V |
| Power Factor |
-1…+1 |
| Rated Grid Frequency |
50Hz |
| Isolation Method |
Non-lsolated |
| Connection Method |
3-Phase, 4-Wire |
| OPERATING ENVIRONMENT |
| Protection Rating |
IP55 |
| Noise Emission |
≤75dB @1M |
| Operating Temperature Range |
-30°C～50°C |
| Relative Humidity |
0～95%(non-condensing) |
| Maximum Operating Altitude |
3000m |
| System Information(Continued) |
| Dimensions(W×HxD) |
1000×2500×1350mm |
| Weight |
2500kg |
| Battery Room Cooling |
Intelligent Liquid Cooling |
| PCS Room Cooling |
Forced Air Cooling |
| Fire Suppression System |
Aerosol+Water Fire Suppression |
| Communication Interface |
CAN/RS485 |
| Communication Protocol |
IEC62619, IEC61000, GB/T 36276 |
