Description

Items	Unit	12000BTU	18000BTU	24000BTU
Mode	/	JPRA-12KCH-G1	JPRA-18KCH-G1	JPRA-24KCH-G1
Power DC, PV, Series Connection	VOC(V)	80~380	80~380	150~410
Power DC, PV, Series Connection	ISC(A)	</=14A	</=14A	</=20A
Grid Power Voltage	VHz	208V~240V/50~60Hz	208V~240V/50~60Hz	208V~240V/50~60Hz
Cooling Capacity(T1)	BTU	12000(3000-13300)	17500(4100-18500)	22000(6100-27000)
Cooling Power Input(T1)	W	940(190-1270)	1510(220-1950)	1790(300~3200)
Heating Capacity	W	3600(900-3960)	5150(1500~5300)	7000(1800-7200)
Heating Power Input	W	940(180~1250)	1400(220~1450)	2030(340~2150)
EER	BTUN	12.66	11.50	12.19
Indoor Unit Dimension(WxHxD)	mm	850×298×200	910×298×230	1030×320×240
Indoor Unit Packing(WxHxD)	mm	875×360×270	970x370x250	1110×405×315
Outdoor Unit Dimension (WxHxD)	mm	760×552×256	823x635x310	890x700x320
Outdoor Unit Packing(WxHxD)	mm	850×590×350	995x675x445	1045x760x445

Items	Unit	12000BTU	18000BTU	24000BTU
Mode	/	JPRB-12KCH-G1	JPRB-18KCH-G1	JPRB-24KCH-G1
Power DC, PV, Series Connection	VOC(V)	80~380	80~380	150~410
Power DC, PV, Series Connection	ISC(A)	</=14A	</=14A	</=20A
Grid Power Voltage	VHz	208V~240V/50~60Hz	208V~240V/50~60Hz	208V~240V/50~60Hz
Cooling Capacity	W	3500(800~3900)	5150(1200~5600)	6400(1800~7800)
Cooling Power Input	W	920(140~1150)	1430(220~2000)	1690(340~2550)
Heating Capacity	W	4000(900~4400)	5150(1200~5300)	7030(1800~7800)
Heating Power Input	W	1020(150~1350)	1340(220~1450)	1780(320~2190)
EER	WN	3.75	3.55	3.75
Indoor Unit Dimension(WxHxD)	mm	850×298×200	910×298×230	1030×320×240
Indoor Unit Packing(WxHxD)	mm	875×360×270	970x370x250	1110×405×315
Outdoor Unit Dimension (WxHxD)	mm	760×552×256	823x635x310	890x700x320
Outdoor Unit Packing(WxHxD)	mm	850×590×350	995x675x445	1045x760x445
