| Technical Data |
Uranus MS1200-G1 |
Uranus MS1400-G1 |
Uranus MS1600-G1 |
Uranus MS1800-G1 |
Uranus MS2000-G1 |
Uranus MS2200-G1 |
Uranus MS2250-G1 |
| PVString Input Data |
| Max.PV Input Power(W) |
210-420(4 Pieces) |
210-490(4 Pieces) |
210-560(4 Pieces) |
210-630(4 Pieces) |
210-700(4 Pieces) |
210-770(4 Pieces) |
210-790(4 Pieces) |
| Max.PV Input Voltage(V) |
60 |
| Start-up Voltage (V) |
20 |
| MPPT Voltage Range(V) |
25-55 |
| Rated PV Input Voltage (V) |
42.5 |
| Max.Operating PV Input Current(A) |
18+18+18+18 |
| Max.Input Short Circuit Current(A) |
27+27+27+27 |
| No.of MPP Trackers/No.of Strings MPP Tracker |
4/1 |
| AC Output Side |
| Rated AC Output Active Power(W) |
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2250 |
| Max AC Output Apparent Power(VA) |
1200 |
1400 |
1600 |
1800 |
2000 |
2200 |
2250 |
| Rated AC Output Current (A) |
5.5/5.2 |
6.4/6.1 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
10/9.6 |
10.3/9.8 |
| Max.AC Output Current(A) |
5.5/5.2 |
6.4/6.1 |
7.3/7 |
8.2/7.9 |
9.1/8.7 |
10/9.6 |
10.3/9.8 |
| Rated Output Voltage/Range (V) |
220/2300.85Un-1.1Un |
| Grid Connection Form |
L/N/PE |
| Rated Output Grid Frequency/Range(Hz) |
50/45-55,60/55-65 |
| Max.Unit per Branch |
5 |
4 |
4 |
3 |
3 |
3 |
3 |
| Power Factor Adjustment Range |
0.9 leading-0.9 lagging |
| Total Current Harmonic Distortion THDi |
<3% |
| DC Injection Current |
<0.5%ln |
| Efficiency |
| Max.Efficiency |
0.965 |
| Euro Efficiency |
0.96 |
| MPPT Efficiency |
>99% |
| Equipment Protection |
| DC Reverse Polarity Protection |
Yes |
| AC Output Overcurrent Protection |
Yes |
| AC Output Overvoltage Protection |
Yes |
| AC Output Short Circuit Protection |
Yes |
| Thermal Protection |
Yes |
| Insulation Impedance Detection |
Yes |
| Anti-island Protection Ptotection |
Yes |
| Surge Protection Level |
TYPE Ⅱ(AC) |
| General Data |
| Operating Temperature Range(℃) |
-40 to+65℃,>45℃ Derating |
| Permissible Ambient Humidity |
0-100% |
| Permissible Altitude(m) |
2000m |
| Noise(dB) |
≤25 |
| Ingress Protection(IP)Rating |
IP67 |
| Inverter Topology |
lsolated |
| Over Voltage Category |
OVC II(DC),OVCII(AC) |
| Communication |
Wi-Fi |
| Cabinet Size(WxH×D)(mm) |
314.3*269.8*40.3(Excluding Connectors and Brackets) |
| Weight (kg) |
5 |
| Warranty |
10 Years |
| Type of Cooling |
Natural Cooling |
| Grid Regulation |
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,G98,G99, VDE-AR-N 4105 |
| Safety EMC/Standard |
IEC/EN 61000-6-1/2/3/4, IEC /EN 62109-1, IEC/EN 62109-2 |
